- Camera
- Image Sensor1/1.2″ Progressive Scan CMOS
- Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light
- Shutter Speed1/3 s to 1/100,000 s
- Slow ShutterYes
- P/NP/N
- Wide Dynamic Range130 dB
- Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
- Lens
- Depth Of Focus
2.8 mm: 4.5 m to ∞
4 mm: 7 m to ∞
6 mm: 13 m to ∞
- Lens Type & FOV
2.8 mm, horizontal FOV102°, vertical FOV 52°, diagonal FOV 124°
4 mm, horizontal FOV 88°, vertical FOV 49°, diagonal FOV 102°
6 mm, horizontal FOV 54°, vertical FOV 30°, diagonal FOV 62°
- ApertureF1.0
- DORI
- DORI
2.8 mm, D: 96 m, O: 38 m, R: 19 m, I: 9 m
4 mm, D: 111 m, O: 44 m, R: 22 m, I: 11 m
6 mm, D: 167 m, O: 66 m, R: 33 m, I: 16 m
- Illuminator
- White Light Range40 m
- Smart Supplement LightYes
- Video
- Max. Resolution
3840 × 2160
- Main Stream
50Hz: 20 fps (3840 × 2160, 3072 × 1728)
25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (3840 × 2160, 3072 × 1728)
30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream
50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
- Third Stream
50Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
60Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240)
- Video Compression
Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeBaseline Profile/Main Profile/High Profile
- H.265 TypeMain Profile
- H.264+Main Stream supports
- H.265+Main Stream supports
- Bit Rate ControlCBR/VBR
- Scalable Video Coding (SVC)
Yes
- Region Of Interest (ROI)1 fixed region for main stream and sub-stream
- Audio
- Audio Compression-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
- Audio Bit Rate-U: 64 Kbps (G.711 ulaw)/64 Kbps(G.711 alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 to 192 Kbps(MP2L2)/8 to 320 Kbps(MP3)/16 to 64Kbps(AAC)
- Audio Sampling Rate-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Environment Noise Filtering-U: Yes
- Network
- Simultaneous Live ViewUp to 6 channels
- APIOpen Network Video Interface (Profile S, Profile G), ISAPI, SDK
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
- User/HostUp to 32 users. 3 user levels: administrator, operator and user
- SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
- Network StorageMicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- ClientiVMS-4200, Hik-Connect, Hik-Central
- Web Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view : Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+
- Image
- Day/Night SwitchDay, Night, Auto, Schedule
- Image EnhancementBLC, HLC, 3D DNR
- Image Parameters SwitchYes
- Image SettingsRotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
- Interface
- Built-In Microphone-U: Yes
- On-Board StorageBuilt-in micro SD/SDHC/SDXC slot, up to 256 GB
- Hardware ResetYes
- Communication Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- Event
- Basic EventMotion detection (human and vehicle), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
- Smart EventScene change detection
- Deep Learning Function
- Face CaptureYes
- Perimeter ProtectionLine crossing detection, intrusion detection, region entrance detection, region exiting detection
- General
- Linkage MethodUpload to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture, send email
- Web Client Language
33 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General FunctionAnti-flicker, heartbeat, password reset via e-mail, pixel counter
- Software ResetYes
- Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Power Supply
12 VDC ± 25%, reverse polarity protection
PoE: 802.3af, Class 3
- Power Consumption And Current
12 VDC, 0.6 A, max. 7 W
PoE (802.3af, 36 V to 57 V), 0.3 A to 0.2 A, max. 8.5 W
- Power InterfaceØ5.5 mm coaxial power plug
- MaterialFront cover: metal, back cover: metal
- Screw MaterialSUS304
- Camera Dimension78.8 × 78.6 × 215.2 mm (3.1″ × 3.1″ × 8.5”)
- Package Dimension315 × 137 × 141 mm (12.4″ × 5.4″ × 5.6″)
- Camera WeightApprox. 860 g (1.9 lb.)
- With Package WeightApprox. 1265 g (2.8 lb.)
- Approval
- ClassClass B
- EMC
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2016)
- Safety
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014)
- EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
- ProtectionIP67 (IEC 60529-2013)
