- Camera
- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.7 mm to 13.5 mm motorized, auto focus
- Focal Length & FOV103° to 32.1°
- Lens MountΦ14
- Image
- Image Parameters SwitchSTD/HIGH-SAT
- Image SettingsBrightness, Sharpness, Mirror, Smart IR
- Frame Rate
PAL: 1080p@25fps
NTSC: 1080p@30fps
- Day/Night ModeAuto/Color/BW (Black and White)
- Image EnhancementBLC, HLC
- White BalanceAuto/Manual
- AGCSupport
- Interface
- Video Output1 HD analog output
- General
- MaterialMetal
- DimensionΦ 145 mm × 111.3 mm (Φ 5.69″ × 4.37″)
- Approx. 890 g (1.96 lb.)
- Operating Condition‘-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power Supply12 VDC ±25%, PoC.af
- ConsumptionMax. 7 W
- IR RangeUp to 60 m
- Approval
- ProtectionIP67, IK10
