| Camera | ||
|---|---|---|
| Image Sensor: | 1/2.8″ Progressive Scan CMOS | |
| Effective Pixels: | 2048(H)x1536(V) | |
| Minimum Illumination: | F1.6, AGC On : Color : 0.05 lux, B/W : 0.01 lux | |
| White Balance: | Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp | |
| AGC: | Auto/Manual | |
| BLC: | ON/OFF | |
| HLC: | Support | |
| WDR: | DWDR | |
| Shutter Time: | 1/1~1/10,000s | |
| Day& Night: | ICR | |
| Digital Zoom: | 16X | |
| Privacy Mask: | 8 programmable privacy masks | |
| Auto Focus: | Auto / Semi-automatic / Manual | |
| Lens | ||
|---|---|---|
| Focal Length: | 2.8~12mm, 4x | |
| Zoom Speed: | Approx.1s(Wide~Tele) | |
| Field of View: | 105~33.5 degree (Wide~Tele) | |
| Aperture Range: | F1.6 ~F2.7 | |
| Pan & Tilt | ||
|---|---|---|
| Pan Range: | Pan: 0~350° | |
| Pan Speed: | Pan Manual Speed: 0.1°~60°/s | |
| Tilt Range: | Tilt: 0°~90° | |
| Tilt Speed: | Tilt Manual Speed: 0.1°~50°/s | |
| Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples | |
| Number of Preset: | 300 | |
| Power-off Memory: | Support | |
| PTZ Position Display: | ON/OFF | |
| Alarm | ||
|---|---|---|
| Alarm Input: | 1 | |
| Alarm Linkage: | Preset, Recording, Relay output, Upload center, Upload FTP, Email linkage | |
| Input & Output | ||
|---|---|---|
| Audio Input: | 1 Mic in/Line in interface Line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10% |
|
| Audio Output: | 1 Audio output interface Line level, impedance: 600Ω |
|
| Network | ||
|---|---|---|
| Ethernet: | 10Base -T, /100Base-TX, RJ45 Connector | |
| Max.Image Resolution: | 2048×1536 | |
| Main Stream: | 50Hz:25fps (2048×1536,1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ; 60Hz:30fps(2048×1536,1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720) |
|
| Sub Stream: | 50Hz:25fps(704×576), 25fps(640×576), 25fps(320×288) 60Hz:30fps(704×480), 30fps(640×480), 30fps(320×240) |
|
| Third Stream: | 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480, 320 × 288) 60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480, 320 × 240) |
|
| Video Compression: | H.264 / MJPEG | |
| ROI encoding: | Support 4 areas with adjustable levels | |
| Audio Compression: | G.711ulaw/G.711alaw/G.726/MP2L2/G.722 | |
| Protocols: | IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP,IGMP, ICMP, DHCP, PPPoE | |
| Simultaneous Live View: | Up to 20 channels | |
| Dual Stream: | Support | |
| Storage: | Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording | |
| User/Host: | Up to 32 users,3 Levels: Administrator, Operator and User | |
| Security Measures: | User authentication (ID and PW), Host authentication (MAC address) IP address filtering |
|
| Hik-Connect: | Support | |
| Client GUI | ||
|---|---|---|
| Date & Time Display: | Time: Week: Date, 6 formats on the Client | |
| Client: | Support iVMS-4200 | |
| Web Browser: | IE 7+, Chrome 18 – 42, Firefox 5.0 +, Safari 5.02 + | |
| General | ||
|---|---|---|
| Language: | English | |
| Power Supply: | 12V DC & PoE((802.3af, class3) | |
| Power Consumption: | Max. 8W | |
| Working Temperature/Humidity: | -30°C ~ 65°C (-22°F ~ 149°F) | |
| Protection Level: | IP67, IK10, TVS 4,000V lightning protection, surge protection and voltage transient protection | |
| Mounting: | Various mounting modes optional | |
| Dimensions: | Φ140.7×107.2mm | |
| Weight (approx.): | 950g | |
| Mount Option: | Wall mount: DS-1273ZJ -PT6; In-ceiling Mount: 1227ZJ-PT6; Junction Box: DS-1280ZJ -PT6 | |
