เครื่องบันทึก Dahua NVR4116HS-4KS2/L
4/8/16 Channel Compact 1U 4K&H.265 Lite Network Video Recorder
· New UI interface with more easier operation experience
· Smart H.265+/ Smart H.264+
· P2P remote surveillance, video play on mobile device
· Supports mainstream cameras of ONVIF and RTSP protocol
· VGA/HDMI simultaneous video output, maximum resolution of HDMI is 4K
· Remote configuration and management of IPCs, such as setting parameters, acquiring information and upgrading IPCs of the same model in batches
· DHCP(Dynamic Host Configuration Protocol), HTTP(Hypertext Transfer Protocol), NTP(Network Time Protocol) and DDNS(Dynamic Domain Name System)
Description
Technical Specification
System
Main Processor Industrial-grade embedded processor
OS Embedded Linux
Operation Interface Web/operating in local GUI
Video
Access Channel 16 channels
Network Bandwidth
80 Mbps for access, 80 Mbps for storage and 60 Mbps
for forwarding
Resolution 8MP/5MP/4MP/3MP/1080P/720P/D1/CIF
Decoding Capability 16–ch@720P(30FPS)
Video Output 1 VGA/1 HDMI simultaneous video output, maximum
resolution 4K
Multi-screen Display 1/4/8/9/16
Third Party Camera Access ONVIF, RTSP
Compression
Video Smart H.265+/H.265/Smart H.264+/H.264
Audio G.711A/G.711U/PCM/G726
Network
Network Protocol HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS,
P2P
Mobile Phone Access iDMSS (iOS)/gDMSS (Android)
Access Standard ONVIF (profile S), CGI, SDK
Browser Chrome, IE9 or above, Firefox
Record Playback
Multi-channel Playback Up to 16 channels playback
Record Mode
Priority of record mode: Manual recording > alarm
recording > motion detection recording > timed
recording
Storage Local HDD
Backup USB device
Playback Function
1. Play, pause, stop, fast forward, fast backward, rewind,
play by frame
2. Full screen, backup (cut/file), partially enlarge, audio
on/off
Alarm
General Alarm Motion detection, privacy masking, video loss, IPC alarm
Anomaly Alarm
Front-end device going offline, storage error, full
storage, IP conflict, MAC conflict, login lock, network
security anomaly
Alarm Linkage Video recording, snapshot, log, preset point, tour
External Port
HDD 1 SATA port, up to 8 TB for a single HDD. The maximum
HDD capacity varies with environment temperature.
USB 1 front USB 2.0 port, 1 rear USB 2.0 port
HDMI 1
VGA 1
RCA Input 1
RCA Output 1
Network 1 RJ–45 port (10/100/1000 Mbps)
General Parameter
Power Supply DC12V, 2A
Power Consumption Total output of NVR is ≤ 10W (without HDD)
Net Weight 0.81kg (1.79 lb) (without HDD)
Gross weight 1.41kg (3.11 lb) (without HDD)
Dimensions 260mm × 225mm × 47.6mm (W × L × H)
10.24 inch × 8.86 inch × 1.87 inch (W × L × H)
Packaging Dimensions 89mm × 333mm × 315mm (W × L × H)
3.50 inch × 13.11 inch × 12.40 inch (W × L × H)
Operating Temperature -10°C to +55°C (+14°F to +131°F)
Storage Temperature 0°C to +40°C (+32°F to +104°F)
Operating Humidity 10%–90%
Storage Humidity 30%–85%
Operating Altitude 3000 m (9843 ft)
Installation Desktop mounting
Certification CE/FCC/UL
