Description

SPECIFICATION
Main chipset CPU: Qualcom QCA9531 560Mhz RAM: 64MDDR2 FLASH: 16MB(RF chip） PA: SE2576L;（Optional）
Antenna Build in 12dBi Smart antenna
Wireless standard Support IEEE802.11.b/g/n
RF parameter Transmitting frequency: 200mW(23dBm) without PA: 14dBm with PA: 23dBm Sensitive: -96dBm working frequency: 802.11.a/n: 2.4GHz Spread spectrum: 2.1GHz-2.6GHz Transmission distance: 1KM
Wireless speed MAX:300Mbps 2KM MIN:100Mbps
Physical port 10/100Mbps WAN RJ45 Ethernet port *1 10/100Mbps LAN RJ45 Ethernet port *1 RESET button*1
Indicator 8个indicator light : Power, WAN, LAN, WIFI, Signal strength
Power Support 802.3af/802.3AT power supplier Power adapter: 15V PoE power adaptor
Power consumption ≤8W
Installation Pole-mounted/wall-mounted/Rack-mounting
Working environment
-40℃to +55℃
