- Camera
- Image Sensor1/1.8″ Progressive Scan CMOS
- Min. Illumination0.0014 @ (F1.0, AGC ON), 0 Lux with Light
- Shutter Speed1/3 s to 1/100,000 s
- Slow ShutterYes
- Day &NightIR cut filter
- Wide Dynamic Range120dB
- Angle AdjustmentPan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
- DNR3D DNR
- Lens
- Focal Length4/6 mm
- ApertureF1.0
- FocusFixed
- FOV
4 mm, horizontal FOV: 94°, vertical FOV: 48°, diagonal FOV: 115°
6 mm, horizontal FOV: 57°, vertical FOV: 31°, diagonal FOV: 67°
- Lens MountM16
- Audio
- Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM
- Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
- Environment Noise FilteringYes
- Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz
- Smart Feature-Set
- Behavior AnalysisLine crossing detection, intrusion detection, object removal detection, unattended baggage detection
- Exception DetectionScene change detection
- Face DetectionYes
- Image
- Max. ResolutionMax. Resolution 2688 × 1520
- Main Stream
50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
- Sub-Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
- Third Stream
50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
60Hz: 30fp s(1280 × 720, 640 × 360, 352 × 240)
- Image EnhancementBLC/3D DNR/HLC
- Image SettingRotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
- Day/Night SwitchDay/Night
- ROISupport 1 fixed region for main stream and sub-stream separately
- Network
- Network StorageSupport micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
- APIONVIF (PROFILE S, PROFILE G), ISAPI
- Simultaneous Live ViewUp to 6 channels
- User/Host
Up to 32 users
3 levels: Administrator, Operator and User
- ClientiVMS-4200, Hik-Connect, iVMS-4500, iVMS-5200
- Web Browser
Plug-in required live view:
IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
Plug-in free live view:
Chrome 45.0+, Firefox 52.0+
- Alarm TriggerMotion detection, video tampering detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error
- General FunctionOne-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Firmware VersionV5.5.82
- Interface
- Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
- Audio
-L model: No
-LU model: 1 audio input (built-in mic), mono sound
-LS model: 1 audio input (line in), 1 audio output (line out), mono sound
-LSU model: 1 audio input (line in), 1 audio output (line out), mono sound
- Alarm1 alarm input, 1 alarm output
- On-Board StorageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB
- Reset ButtonYes
- Compression Standard
- Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
- H.264 TypeMain Profile/High Profile
- H.264+Main stream supports
- H.265 TypeMain Profile
- H.265+Main stream supports
- Video Bit Rate32 Kbps to 16 Mbps
- General
- Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
- Power Supply
12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
- Power Consumption And Current
Power Consumptiont12 VDC, 0.5 A, max. 6 W
PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 7.5 W
- MaterialCamera: Metal, trim ring: Plastic
- Dimensions
DimensiontCamera: Φ 138.3 × 125.2 mm (Φ 5.4\” × 4.9\”)
With package: 170 × 170 × 150 mm (7 × 7\” × 5.9\”)”
-
-L/-LU model: Camera: 575 g (1.3 lb.); With package: 833 g (1.8 lb.)
-LS/-LSU model: Camera: 860 g (1.9 lb.); With package: 1133 g (2.5 lb.)
- Protection Level
-L/-LS model: IP67
-LU/-LSU model: IP66
- Visible Light RangeUp to 30m
