| Specifications |
| Model |
CS-CMT-Solar Panel-D |
| Performance Parameter |
| Open Circuit Voltage |
7.2V±5% |
| Short Circuit Current |
740mA±5% |
| Power Voltage |
6.0V±5% |
| Max. Power Current |
700mA±5% |
| Max. Power |
4.2W |
| Solar Cell Efficiency |
0.216 |
| Operation Temperature |
-20℃~60℃ (-4℉~140℉),Humidity 90% or less (non-condensing) |
| IP Grade |
IP65 |
| Mechanical Data |
| Solar Cell Type |
Monocrystalline solar cells |
| Product Dimensions |
222.6 × 155.9 × 14.9 mm (8.76 × 6.14 × 0.59 inch) |
| Packaging Dimensions |
230 × 161 × 78 mm (9.06 × 6.34 × 3.07 inch) |
| Weight |
With package: 611 g (21.5 oz) |
| Panel body without bracket: 334 g (11.78 oz) |
| In the box |
| In the box |
– EZVIZ Solar Panel-D |
| – Adjustable Mounting Bracket |
| – Screw Kit |
| – Drill Template |
| – Quick Start Guide |
| Certifications |
| Certifications |
RoHS \ WEEE \ REACH |
