- Interfaces
- Barrier Interface1, barrier Interface, including barrier control and status feedback
- Inductive Loops Input Interface1, inductive loops input interface
- LED Interface1, external LED interface
- Card Reader Interface1, user card reader interface
- Vehicle Detector Interface1, vehicle detector interface
- Wiegand Interface2, Wiegand interface
- Loudspeaker Interface1, loudspeaker interface
- RS-232 Interface1, RS-232 interface
- RS-485 Interface1, RS-485 interface
- USB Interface2, USB 2.0 interface
- VGA Interface1, VGA interface
- Network Interface1, 100M Ethernet interface
- General
- Working Temperature-25 ºC to +75 ºC (-13 ºF to +167 ºF)
- Working Humidity10% to 90%
- Consumption< 150 W
- Device Dimension (W × D × H)410 × 350 × 1405 mm (16.1 × 13.8 × 55.3 inch)
- Power Supply100 to 240 VAC, standard
- Function Parameters
- Memory CardUp to 350 memory cards supported
- DisplayLED electronic display
- Display Dimension (W × H)305 × 76 mm (12.0 × 3.0 inch)
- Data Storage
Information storage of the passing vehicle
Storage capacity: 1 GB
- Data UploadData upload and video stream transfer
- System
- Operating SystemEmbedded Linux operating system
- Operation InterfaceVGA, WEB
- Indicator
24V power supply indicator, 12V power supply indicator, mainboard alarm indicator,
HDD read/write indicator, mainboard running status indicator
- Input/Output Parameters
- Analog Video Input2-ch, SD BNC input
- Network Video Input4-ch, IP camera input
- Audio Input1-ch, pickup input
- Audio Output1-ch, loudspeaker output
- Alarm Input2-ch, alarm input
- Alarm Output2-ch, alarm output
- Reserved Interface1-ch, fire alarm input and alarm output
