- Facial Recognition
- Facial Detection And Analytics8-ch human face capture (HD network camera, up to 4 MP, H.264/H.265)
- Face Picture Library32 libraries；100, 000 pictures
- Face Picture Comparison
16-ch face pictures comparison alarm,
Alarm linkage actions: recording, audio warning, notify surveillance center, send email
- Perimeter Protection
- Human/Vehicle AnalysisUp to 16-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
- Video And Audio
- IP Video Input16-ch
- HDMI 1 Output
VGA1: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- HDMI 2 Output1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
- Incoming Bandwidth320 Mbps/256 Mbps
- Incoming Bandwidth (RAID Mode)200 Mbps/200 Mbps
- Audio Output2-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding
- Decoding FormatH.265/H.265+/H.264/H.264+/MPEG4
- Decoding Capability16-ch @ 1080p
- Synchronous Playback16-ch
- Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF
- Network
- Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- RAID
- RAID TypeRAID0, RAID1, RAID5, RAID6, RAID10
- Auxiliary Interface
- SATA8 SATA interfaces
- ESATA1 eSATA interface
- CapacityUp to 10 TB capacity for each HDD
- Serial InterfaceRS-232; RS-485; Keyboard
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- Alarm In/Out16/4 (16/8 is optional)
- General
- Power Supply100 to 240 VAC, 50 to 60 Hz
- Consumption≤ 70 W
- Working Temperature-10 to +55° C (+14 to +131° F)
- Working Humidity10 to 90%
- Dimension (W × D × H)445 × 465 × 88 mm (17.5″× 18.3″ × 3.5″)
- ≤ 10 kg (22 lb)
