LONGI LNG-LR572HPH555M

Sale!
JSR-JAM72S30-550GR
JAM72S30-550/MR
LNG-LR572HPH555M

LONGI LNG-LR572HPH555M

Original price was: 7,159.00฿.Current price is: 6,828.00฿.

Longi 545W Solar Panel Mono Crystalline Half Cell (LR5-72HPH-545M)

  • Based on M10 wafer, best choice for ultra-large power plants
  • Advanced module technology delivers superior module efficiency
  • Excellent outdoor power generation performance
  • High module quality ensures long-term reliability
  • 12-year Warranty for Materials and Processing
  • 25-year Warranty for Extra Linear Power Output
Categories: , Tags: ,

Description

Longi Solar Panels
• Module Type: LR5-72HPH-545M
• Cell: Half Cell, Mono Crystalline
• No. of Cells: 144(6×24)
• Glass: Single glass, 3.2mm coated tempered glass
• Junction Box: IP68, three diodes
• Connector: MC4

Electrical Parameters at STC
• Maximum Power(Pmax/w) : 545W
• Voltage at Maximum Power (Vmp/V) : 41.80VDC
• Current at Maximum Power (Imp/A) : 13.04A
• Open Circuit Voltage(Voc/V) : 49.65VDC
• Short Circuit Current(Isc/A) : 13.92A
• Module Efficiency : 21.1%

Operating Parameters
• Maximum System Voltage : DC1500V(IEC/UL)
• Maximum Series Fuse Rating : 25A
• Operating Temperature : -40°C to 85°C

Product Certifications
• IEC 61215
• IEC 61730
• UL 61730
