SPECIFICATION
Main chipset
Qualcomm Qualcomm AR9344 560Mhz frequency industrial grade
CPU; memory: 64MB;
Flash memory: 16MB;
Power amplifier chip: SKY85728-11
Antenna
11dBi
Wireless standard
Support IEEE802.11a/an standard
RF parameter
Maximum transmission power: 200mW (23dBm) Maximum
receiving sensitivity: -96dBm Operating frequency: 802.11.a/n: 5.8GHz
Spreading frequency: 4. 7 GHz- 6. 1 GHz Transmission distance: 3 KM
Modulation technique
DSSS : DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps
OFDM : BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps,
64-QAM@48/54Mbps MIMO-OFDM : MCS 0-15
Wireless speed
MAX:300Mbps When arrived 5KM, MIN:50Mbps
Physical port 10/100Mbps WAN RJ45 Ethernet port *1 10/100Mbps LAN RJ45 Ethernet port *1 RESET button*1
Indicator
8 indicators: power, WAN, LAN, WIFI, signal strength (1-4 grids)
Power
9-24V PoE power supply
Protection level
2KV lightning protection
IP63 rating
Power consumption ≤8W
MTBF
>250000H
Installation method
Pole mounting
Housing
Imported ABS material, plastic case
Physical characteristics
Dimensions: 198*110*59mm Weight: 280g
