Capacity
Faces
30,000 (1:N) / 50,000 (Optional)
Users / Cards
50,000
Transactions
1,000,000
User Photos
30,000
Event Photos
10,000
Compatibility
Security Relay Box / Wiegand / RS485 / RS232 Slave Reader with FP / RFID / Barcode / QR-code / ZKBioSecurity Software
Hardware
900MHz Dual Core Customized CPU
512MB RAM / 8G Flash
8″ High Brightness (400lux) IPS Touch LCD
125KHz EM Reader / 13.56MHz MF (Optional)
2MP WDR Low Light Camera
Brightness Adjustable LED
Hi-Fi audio
Microphone with Sensitivity Receiver
Distance Detection Sensor
Reset Button and Tamper Switch
Access Control Interface
Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensor
Special Functions
IP68 & IK04
0.3s High Speed Faceial Recognition
Face Liveness Detection
Communication Https Encryption (Optional)
Event Snapshot
Standard Functions
Access Levels, Groups, Holidays, DST,Duress Mode (Password), Anti-Passback,Record Query, Custom Wallpaper &Screen Saver, Tamper Switch Alarm
Additional Info
Face Algorithm
ZKLiveFace5.8
Working Temperature
-30°C ~ 60°C,(-22°F~ 140°F)
Working Humidity
≤93%
Storage Temperature
-40°C ~ +65°C
Storage Humidity
≤93%
Net Weight
853g
Dimensions (H*L*D)
227*143*26mm
Power
Operating Voltage 12V DC
Current Draw < 2,000mA
